SitePro RD302 Rotary Laser Receiver, with Large 5-inch Capture Window
SitePRO 27-RD302
Professional Laser Detector with Digital Readout
This is a versatile laser detector for basic and advanced leveling and alignment. Digital readout provides a numeric display and shows exactly how far the elevation is from on-grade. The rotary laser detector aids in locating and targeting a visible or invisible beam emitted by a rotary laser instrument; perfect for use in outdoor conditions (as well as indoors), where sunlight and distance may make locating the beam more difficult. The laser detector includes a rod clamp which allows to mount the detector onto square, round or oval sighting rods.
- LARGE 5-INCH Capture window allows for faster beam detection.
- Digital readout on front and back - displays elevation from on-grade within 2 inches above or below on grade.
- Selectable units of measure - mm or inches
- Front and Back Displays
- Rugged housing and gasket sealed for water and dust protection (IP55)
- Heavy duty built-in magnets on both side and top for added versatility when mounting detector
- Automatic shut-off turns off receiver after seven (7) minutes of inactivity to preserve battery life
- Simulaneous Elevation LED indicators on front for fast visual detection
- Includes heavy-duty construction tough rod clamp and built-in bubble
- Strong built-in magnets on top and side.
- Back-lit Display
SitePRO RD-302 Laser Receiver INCLUDES:
- Heavy-Duty Rod Clamp
- 9-Volt battery
Site Pro RD-302 Laser Receiver SPECIFICATIONS
-
Beam Detection: Red Laser
-
Capture Window: 5.0-inch
-
Detecting Range: 4-foot to 1,000 foot (Dependent on Laser Transmitter Output)
-
LED Indicators: Green On-Grade , Red High/Low Indicator
- Speaker Tones: Fast Beep - High , Slow Beep - Low , Constant Tone - On Grade
-
Speaker Volume: LOW / HIGH / OFF
-
Reception Sensitivity Settings: Fine / Medium / Coarse
-
LCD Display: Front and Back
- Power Source: 9V, Provides approximately 8 hours of continuous use
-
Weight: 0.85 lbs
- Warranty: 1 Year limited
